SB 200 SB202-9

Technical Details

Bore Diameter (mm) d	Outer Diameter (mm) D	Width (mm) B	Weight (Kg)
9/16	1.5748	0.8661	0.1

KZ SERIES :SB201, SB201-8, SB204, SB205-13, SB206

The SB 200 SB202-9 Series Stainless steel bearings not only have the characteristics of the ordinary bearings: Low vibration, low noise, high precision rotating, lower friction torque, and high speed running but also have a special usage function. The range of applications is wide:

It is an acid-proof and alkali-proof
It can work in corrosion mediums such as seawater, river aqua, distilled water, sparse nitric acid, maritime climate, steam, and so on.
It can work in the high or low-temperature environment

Applications and industry: AGRICULTURE, AUTOMOTIVE, CEMENT INDUSTRY, CRUSHER INDUSTRY, HEAVY MACHINERY EQUIPMENTS, HOME APPLIANCES, MINING SECTOR, METAL INDUSTRY, FLUID MACHINERY, TEXTILE INDUSTRY

Send query Buy Now

Bearing Number	Inner Diameter (d) MM	Width (B) MM	Dynamic Load Capacity	Static Load Capacity	Weight (KG)
SB202-9	9/16	0.8661	9600	4600	0.1
SB202-10	5/8	0.8661	9600	4600	0.1
SB203	17	22	9600	4600	0.09
SB203-11	11/16	0.8661	9600	4600	0.09
SB204	20	25	12800	6600	0.13
SB204-12	3/4	0.9843	12800	6600	0.14
SB205	25	27	14000	7850	0.16
SB205-13	13/16	1.063	14000	7850	0.19
SB205-14	7/8	1.063	14000	7850	0.18
SB205-15	15/16	1.063	14000	7850	0.17
SB205-16	1	1.063	14000	7850	0.16
SB206	30	30	19450	11250	0.25
SB206-17	1-1/16	1.1811	19450	11250	0.28
SB206-18	1-1/8	1.1811	19450	11250	0.26
SB206-19	1-3/16	1.1811	19450	11250	0.25
SB206-20	1-1/4	1.1811	19450	11250	0.24
SB207	35	32	25700	15200	0.36
SB207-20	1-1/4	1.2598	25700	15200	0.41
SB207-21	1-5/16	1.2598	25700	15200	0.39
SB207-22	1-3/8	1.2598	25700	15200	0.36
SB207-23	1-7/16	1.2598	25700	15200	0.35
SB208	40	34	29500	18100	0.45
SB208-24	1-1/2	1.3386	29500	18100	0.43
SB208-25	1-9/16	1.3386	29500	18100	0.45
SB209	45	41.2	32700	20900	0.54
SB209-26	1-5/8	1.622	32700	20900	0.54
SB209-27	1-11/16	1.622	32700	20900	0.54
SB209-28	1-3/4	1.622	32700	20900	0.54
SB210	50	43.5	35000	23200	0.62
SB210-29	1-13/16	1.7126	35000	23200	0.62
SB210-30	1-7/8	1.7126	35000	23200	0.62
SB210-31	1-15/16	1.7126	35000	23200	0.62
SB210-32	2	1.7126	35000	23200	0.62
SB211	55	45.3	43300	29200	0.81
SB211-32	2	1.7835	43300	29200	0.81
SB211-33	2-1/16	1.7835	43300	29200	0.81
SB211-34	2-1/8	1.7835	43300	29200	0.81
SB211-35	2-3/16	1.7835	43300	29200	0.81
SB212	60	53.7	47700	32800	1.14
SB212-36	2-1/4	2.1142	47700	32800	1.14
SB212-37	2-5/16	2.1142	47700	32800	1.14
SB212-38	2-3/8	2.1142	47700	32800	1.14
SB212-39	2-7/16	2.1142	47700	32800	1.14
