LMB LMB16
Technical Details
| Bore Diameter (mm) d | Outer Diameter (mm) D | Width (mm) B | Weight (Kg) |
|---|---|---|---|
| 25.4 | 39.688 | 0.22 |
LMB16 Avail from us a wide range of Linear Motion Systems, as we are producers and manufacture these products in bulk as per the requirements of our customers. These systems are technically accurate and offer a high level of performance. High tensile strength and longer functional life are some of the main specifications of our clients. All these products are available in different sizes and dimensions.
Features :
- Durable
- Cost-effective
- Longer operational life
Applications and industry: AGRICULTURE, AUTOMOTIVE, CEMENT INDUSTRY, CRUSHER INDUSTRY, HEAVY MACHINERY EQUIPMENTS, HOME APPLIANCES, MINING SECTOR, METAL INDUSTRY, FLUID MACHINERY, TEXTILE INDUSTRY
| Bearing Number | Inner Diameter (d) MM | Outer Diameter (D) MM | L | C | Height | C0 | r2 min | Weight (KG) | GOST |
|---|---|---|---|---|---|---|---|---|---|
| LMB16 | 25.4 | 39.688 | 57.15 | 980 | 1570 | 0.22 | |||
| LMB20 | 31.75 | 50.8 | 66.675 | 1570 | 2740 | 0.465 | |||
| LMB24 | 38.1 | 60.325 | 76.2 | 2180 | 4020 | 0.72 | |||
| LMB32 | 50.8 | 76.2 | 101.6 | 3820 | 7940 | 1.31 | |||
